| Machine reference | COLA 062 |
| Manufacturer | COMEXI |
| Type | SOLVENTLESS LAMINATING |
| Model | SL2 (sp) |
| Year | 2020 |
| Type of application | Solventless |
| Type of coating & laminating | Coating 5 rolls, and 3 rolls for laminating, 1 chill roll |
| product to be coated/laminated | Paper/alu, Paper/film, Paper/Paper, Film/film, Film/alu (adapted to tension range) |
| Web width (mm) | 1330 mm |
| Working width (mm) | 500 – 1315 mm |
| Speed (m/min) | Up to 500m/min, depend materials |
| Primary unwinder | Shaftless, mono, motorized, tension control, dancing roller, core dia. 3 »,6 », reels weight 1000kg, tension range 20-550N |
| Reels diameter (mm) | 1000 mm |
| Secondary unwinder | Shafted, mono, motorized, tension control dancing roller, core dia. 3 »,6 », reels weight 2000kg, tension range 40-7O0 N, reels loading device |
| Reels diameter (mm) | 1500 mm |
| Rewinder | Shafted, mono, tension control, dancing roller, core dia. 3 »,6 », reels weight 1500kg, tension range 45-900 N, reels unloading device |
| Reels diameter (mm) | 1500 mm |
| Coating unit | Solventless technology, sleeve for glue transfer, heat exchanger |
| Drying system | No |
| Web guide system | Yes for both unwinds |
| Mixer / Pumps | 1 mixer for Bi-component, 1 mono component dispenser |
| Register Control | No |
| Corona treatment | No |
| Additional information | Trolleys for reels, around 10 sleeves, chiller for chill roll, heated blanket for 200l barrel (mono dispenser), fume exhaust fan |
